J.A. Becker Piston Lift
Environmentally Friendly Piston Style Inground Lift
WEIGHT: 8,000 lbs to 200,000 lbs
USE: Car dealerships, tractor trailers, buses, public works facilities, wash bays
FEATURES:
- ground position switch alerts the operator when the lift is in a fully lowered position, protecting the lifting equipment and the vehicle.
- automatic wheel base positioning – up to 14 positions can be stored to vary wheel bases for the moveable ram.
- programmable height setting can store up to 4 height settings.
- liquid detection system alerts the operator when there is at least 3” of liquid in the concrete vault or steel cassette. A suction tube allows evacuation of liquids in vault or cassette.
- flush mounted head plates maintain a completely flat floor.
- rolling trench covers keep the floor completely flat
- 11,000 lb. wheel pressure.
- epoxy coating can be applied to the lifting cylinders and the steel cassettes which reduces electrolysis and corrosion while in the ground.
- Can be installed in a concrete vault, a steel cassette, or retro-fitted in an existing concrete pit.
- Piston stroke for all models is 75 inches.
- Solid steel locking bars with Nitro Carburizing surface treatment for superior corrosion resistance.
